The ETR-250 Rotary Stamping Machine is designed to either stamp/cut the dough sheet from the 11-Layer Drying/Cooling Conveyor, into any 2D shapes or stamp / cut the aged dough sheet into 2D shapes directly from the Winding Machine.

SPECIFICATIONS

Capacity:
200 kgs/hr depending on shape/design

Power Requirement:
4 Kilowatts

Forming rollers:
2 X 123 mm dia., 410 mm (W)

Dimension:
1,230 mm (L) X 1,680 mm (W) X 1,160 mm (H)

Dimension:
13,880 mm (L) x 1,130 mm W x 2,630 mm (H)
